A Real-World Evaluation of Optical Coherence Tomography Angiography and Clinical Risk Factors for Mild Non-Proliferative Diabetic Retinopathy
Keywords:
Optical coherence tomography angiography, Superficial vessel density, Deep vessel density, Non-proliferative diabetic retinopathy, Hemoglobin A1c (HbA1c), Diabetes durationAbstract
Objectives: To evaluate the clinical utility of optical coherence tomography angiography (OCTA) metrics for detecting mild non-proliferative diabetic retinopathy (NPDR) and to identify clinical risk factors associated with mild NPDR.
Methods: This prospective cross-sectional study included patients with type 2 diabetes mellitus (DM). OCTA metrics—including superficial and deep capillary plexus vessel densities (SVD and DVD), ganglion cell complex (GCC) thickness, and foveal avascular zone (FAZ) area—were measured in the parafoveal region using the Optovue Solix OCTA system. Logistic regression analysis adjusted for potential confounders was performed to evaluate associations between OCTA metrics, clinical risk factors, and mild NPDR.
Results: A total of 236 patients were enrolled, including 118 patients without DR and 118 with mild non-proliferative diabetic retinopathy (NPDR). SVD was significantly lower in the mild NPDR group compared to the no DR group (48.37 ± 2.25% vs. 49.22 ± 2.82%, p = 0.011), whereas other OCTA parameters showed no significant differences between groups. In adjusted logistic regression analyses, the presence of mild NPDR was significantly associated with SVD (p < 0.001), DVD (p = 0.003), and age (p = 0.001).
Conclusions: Although SVD was statistically reduced in patients with mild NPDR, the magnitude of difference was not clinically meaningful. Nonetheless, vessel density metrics and age were significantly associated with mild NPDR. While OCTA provides valuable quantitative assessment of retinal microvasculature, its utility as a routine screening tool for mild NPDR remains limited. Clinical fundoscopy continues to be the primary method for diagnosing mild NPDR.
References
Yau JWY, Rogers SL, Kawasaki R, et al; Meta-Analysis for Eye Disease (META-EYE) Study Group. Global prevalence and major risk factors of diabetic retinopathy. Diabetes Care. 2012;35(3):556-564.
Ong CJT, Wong MYZ, Cheong KX, et al. Optical coherence tomography angiography in retinal vascular disorders. Diagnostics. 2023;13(9):1620.
Durbin MK, An L, Shemonski ND, Soares M, et al. Quantification of retinal microvascular density in optical coherence tomography angiography images in diabetic retinopathy. JAMA Ophthalmol. 2017;135(4):370-376.
Mokrane A, Zureik A, Bonnin S, et al. Retinal sensitivity correlates with the superficial vessel density and inner layer thickness in diabetic retinopathy. Invest Ophthalmol Vis Sci. 2021;62(11):28.
Li X, Yu Y, Liu X, Shi Y, et al. Quantitative analysis of retinal vessel density and thickness changes in diabetes mellitus evaluated using optical coherence tomography angiography: a cross-sectional study. BMC Ophthalmol. 2021;21:259.
Kim T-Y, Song Y-Y, Il-Jung, et al. The impairment of the deep vascular complex in prolonged type 2 diabetes patients without clinical diabetic retinopathy. PLoS One. 2022;17(6):e0269182.
Ashraf M, Sampani K, Clermont A, et al. Vascular density of deep, intermediate, and superficial vascular plexuses are differentially affected by diabetic retinopathy severity. Invest Ophthalmol Vis Sci. 2020; 61(8):53.
Zeng Y, Cao D, Yang D, et al. Retinal vasculaturefunction correlation in non-proliferative diabetic retinopathy. Doc Ophthalmol. 2020;140(2):129-138.
Li Q, Wang M, Li X, et al. Aging and diabetic retinopathy: Inherently intertwined pathophysiological processes. Exp Gerontol. 2023;177:112138.
Leley SP, Ciulla TA, Bhatwadekar AD. Diabetic retinopathy in the aging population: A perspective of pathogenesis and treatment. Clin Interv Aging. 2021;16:1367–1378.
Zhang Z, Lv D, You Y, et al. Assessing the importance of risk factors for diabetic retinopathy in patients with type 2 diabetes mellitus: Results from the classification and regression tree models. J Family Community Med. 2024;31(3):197-205.
Boonsaen T, Choksakunwong S, Lertwattanarak R. Prevalence of and factors associated with diabetic retinopathy in patients with diabetes mellitus at Siriraj Hospital – Thailand’s largest national tertiary referralcenter. Diabetes Metab Syndr Obes. 2021;14:4945– 4957.
Waheed NK, Rosen RB, Jia Y, et al. Optical coherence tomography angiography in diabetic retinopathy. Prog Retin Eye Res. 2023;97:101206.
Liu J, He Y, Kong L, et al. Study of foveal avascular zone growth in individuals with mild diabetic retinopathy by optical coherence tomography. Invest Ophthalmol Vis Sci. 2023;64(9):21.
Salvi L, Plateroti P, Balducci S, et al. Abnormalities of retinal ganglion cell complex at optical coherence tomography in patients with type 2 diabetes: a sign of diabetic polyneuropathy, not retinopathy. J Cell Sci. 2024;137(15):260290.
Vision Loss Expert Group of the Global Burden of Disease Study, GBD 2019 Blindness and Vision Impairment Collaborators. Global estimates on the number of people blind or visually impaired by diabetic retinopathy: a meta-analysis from 2000 to 2020. Eye. 2024;38:2047-57.
Liu L, Quang ND, Banu R, et al. Hypertension, blood pressure control and diabetic retinopathy in a large population-based study. PLoS One. 2020; 15(3):e0229665.
Zhang M, Wu J, Wang Y, et al. Associations between blood pressure levels and diabetic retinopathy in patients with diabetes mellitus: A population-based study. Heliyon. 2023;9(6):e16830.
Chou Y, Ma J, Su X, et al. Emerging insights into the relationship between hyperlipidemia and the risk of diabetic retinopathy. Lipids Health Dis. 2020;19:241.
Zhou Y, Wang C, Shi K, et al. Relationship between dyslipidemia and diabetic retinopathy: a systematic review and meta-analysis. Medicine (Baltimore). 2018;97(36):e12283.
Zegeye AF, Temachu YZ, Mekonnen CK. Prevalence and factors associated with diabetic retinopathy among type 2 diabetic patients at Northwest Amhara Comprehensive Specialized Hospitals, Northwest Ethiopia. BMC Ophthalmol. 2023;23:9.
Zhang B, Zhang B, Zhou Z, et al. The value of glycosylated hemoglobin in the diagnosis of diabetic retinopathy: a systematic review and meta-analysis. BMC Endocr Disord. 2021;21:82.
