Method Development and Validation for Determination of Total and Free Polysaccharide Content in Heamophilus influenzae Type B Vaccine by HPAEC-PAD
Method Development and Validation for Determination of Polysaccharide Content in Heamophilus influenzae Type B Vaccine by HPAEC-PAD
Keywords:
The Haemophilus influenzae type b vaccine, Polysaccharide content, HPAEC-PAD, Method validationAbstract
The Haemophilus influenzae type b (Hib) vaccine is used to prevent meningitis and pneumonia in young children. It is produced from the polysaccharide component of Haemophilus influenzae type b. In the quality control of the Hib vaccine, determining the total and free polysaccharide contents is a crucial parameter, and the World Health Organization (WHO) recommends using the HPAEC-PAD method for analysis due to its accuracy and precision, which is well-suited for detecting polysaccharides. This study, the method involved using an anion exchange column with a column temperature of 30°C, a mobile phase of 580 mM NaOH, a flow rate of 0.4 mL/min, and an injection volume of 50 μL. Detection was performed using a PAD detector. The results showed that the standard curve was linear in the concentration range from 0.15 to 10.50 μg/mL, with a correlation coefficient of 0.9999. The precision on the same day showed the relative standard deviations for total and free polysaccharide contents of 3.38% and 1.61%, respectively, while intermediate precision showed the relative standard deviations of 4.47% and 3.22%, respectively. The method was accurate, with the recovery of standard substances added to the DTP-HB-Hib combined vaccine ranging between 96.74% and 103.37%. The method demonstrated specificity and capability of analyzing polysaccharide content in the vaccine from 0.15 μg/mL. Additionally, column temperature and acid hydrolysis duration were found to affect the analysis. In conclusion, this method can be used as an analytical method in the laboratory of the Institute of Biological Products, Department of Medical Sciences, Thailand for the Hib vaccine quality control purposes.
References
อัจฉรา ตั้งสถาพรพงษ์. วัคซีนป้องกันโรคติดเชื้อฮิบ. [ออนไลน์]. [สืบค้น 4 ก.ค. 2567]; [10 หน้า]. เข้าถึงได้จาก: URL: http://pidst.or.th/userfiles/33_วัคซีนป้องกันโรคติดเชื้อฮิบ.pdf
Muangchana C, Chunsuttiwat S, Rerks-Ngarm S, Kunasol P. Bacterial meningitis incidence in Thai children estimated by a rapid assessment tool (RAT). Southeast Asian J Trop Med Public Health 2009; 40(3): 553-62.
World Health Organization. Haemophilus influenzae type b (Hib). [online]. [cited 2024 Jul 2]. Available from: URL: https://www.who.int/teams/health-product-policy-and-standards/standards-and-specifications/normsand-standards/vaccine-standardization/hib
Zarei AE, Almehdar HA, Redwan EM. Hib vaccines: past, present, and future perspectives. J Immunol Res. [online]. 2016; [cited 2024 Jul 10]; [18 screens]. Available from: URL: https://onlinelibrary.wiley.com/doi/10.1155/2016/7203587
กองโรคป้องกันด้วยวัคซีน กรมควบคุมโรค กระทรวงสาธารณสุข. ตำราวัคซีนและสร้างเสริมภูมิคุ้มกันโรคปี 2562. [ออนไลน์]. [สืบค้น 4 ก.ค. 2567]. เข้าถึงได้จาก URL: https://ddc.moph.go.th/uploads/publish/938420191209023015.pdf
World Health Organization. Recommendations for the production and control of Haemophilus influenzae type b conjugate vaccines. WHO Technical Report Series No. 897. [online]. 2000; [cited 2024 Jul 9]; [34 screens]. Available from: URL: https://www.who.int/publications/m/item/hib-conjugate-vaccines-annex-1-trsno-897
Rohrer JS. Vaccine quality ensured by highperformance anion-exchange chromatography with pulsed amperometric detection. SLAS Technol 2020; 25(4): 320-8.
NIBSC. Haemophilus Influenzae polysaccharide polyribosyl ribitol phosphate (PRP) (2nd International Standard). [online]. 2024; [cited 2024 Jul 8]. Available from: URL: https://nibsc.org/products/brm_product_catalogue/detail_page.aspx?catid=12/306
Sigma-aldrich. Adonitol. [online]. 2024; [cited 2024 Jul 8]. Available from: URL: https://www.sigmaaldrich.com/TH/en/product/sigma/a5502
Rosskopf U, Daas A, Terao E, von Hunolstein C. Collaborative study on saccharide quantification of the Haemophilus influenzae type b component in liquid vaccine presentations. Pharmeur Bio Sci Notes 2017; 2017: 44-68.
Jing T, Dan Z, Hong L, Ya-nan L, Mao-guang L, Cui-ping C, et al. Determination of polysaccharide and free polysaccharide contents of Haemophilus influenzae type b conjugate vaccine by high performance anion-exchange chromatography with pulsed amperometric detection. Chin J Pharm Anal 2016; 36(10): 1804-9.
Bardotti A, Ravenscroft N, Ricci S, D’Ascenzi S, Guarnieri V, Averani G, et.al. Quantitative determination of saccharide in Haemophilus influenzae type b glycoconjugate vaccines, alone and in combination with DPT, by use of high-performance anion-exchange chromatography with pulsed amperometric detection. Vaccine 2000; 18(19): 1982-93.
ICH. Validation of analytical procedures: text and methodology Q2(R1). Paper presented at International Conference on Harmonization of technical requirements for registration of pharmaceuticals for human use. Current Step 4 version. [online]. 2005; [cited 2024 Jun 27]; [17 screens]. Available from: URL: https://database.ich.org/sites/default/files/Q2%28R1%29%20Guideline.pdf
ทิพวรรณ นิ่งน้อย. แนวปฏิบัติการทดสอบความถูกต้องของวิธีวิเคราะห์ทางเคมีโดยห้องปฏิบัติการเดียว: คุณลักษณะเฉพาะของวิธีวิเคราะห์ การหาและการประเมิน การยอมรับ. นนทบุรี: กรมวิทยาศาสตร์การแพทย์ กระทรวงสาธารณสุข; 2549. หน้า 39-86.
Dische Z, Schwarz K. Microchemical method for the determination of different pentoses in the presence of other pentoses and hexoses. Mikrochem Acta 1937; 2: 13-8.
Chen PS, Toribara TY, Warner H. Microdetermination of phosphorus. Anal Chem 1956; 28(11): 1756-8.
วิริยามาตย์ เจริญคุณธรรม, ชลดา เพ็ชรไทย, กนกพร ฤทธิธรรม, สุภาพร ภูมิอมร. การตรวจสอบความถูกต้องของวิธี High performance anion exchange chromatography with pulse amperometric detection ในการวิเคราะห์ปริมาณแอนติเจนของวัคซีนป้องกันโรคจากเชื้อ Haemophilus influenzae type b. ว วิชาการสาธารณสุข 2562; 28(3): 561-72.
Giannelli C, Cappelletti E, Di Benedetto R, Pippi F, Arcuri M, Di Cioccio V, et al. Determination of free polysaccharide in Vi glycoconjugate vaccine against typhoid fever. J Pharm Biomed Anal 2017; 139: 143-7.
Gao F, Beresford N, Lockyer K, Burkin K, Rigsby P, Bolgiano B. Saccharide dosage content of meningococcal polysaccharide conjugate vaccines determined using WHO international standards for serogroup A, C, W, Y and X polysaccharides. Biologicals 2021; 70: 53-8.
Cook MC, Gibeault S, Filippenko V, Ye Q, Wang J, Kunkel JP. Serogroup quantitation of multivalent polysaccharide and polysaccharideconjugate meningococcal vaccines from China. Biologicals 2013; 41(4): 261-8.
Gudlavalleti SK, Crawford EN, Harder JD, Reddy JR. Quantification of each serogroup polysaccharide of Neisseria meningitidis in A/C/Y/W-135-DT conjugate vaccine by high-performance anion-exchange chromatography-pulsed amperometric detection analysis. Analytical Chem 2014; 86(11): 5383-90.
ความแรงวัคซีนป้องกันโรคเยื่อหุ้มสมองอักเสบจากเชื้อฮิบ (Haemophilus influenzae type B; Hib). ใน: ระเบียบกรมวิทยาศาสตร์การแพทย์ ว่าด้วยอัตราค่าบำรุงการตรวจวิเคราะห์และให้บริการ ฉบับใช้พลางก่อน (2 พ.ย. 2566). [ออนไลน์]. 2566; [สืบค้น 26 ก.ย. 2567]. เข้าถึงได้จาก: URL: https://service.dmsc.moph.go.th/dmscservice
